A multi-account API gateway for Grok Build, Grok Web, and Grok Console

English | 简体中文

Want to sponsor this project?

	Thanks to APIMart for sponsoring this project! APIMart is a low-cost API platform for AI image & video generation — GPT-Image-2 from $0.006/image, 160+ images per dollar. One async API covers both image and video: submit a task, get an ID, fetch results via polling or callback. Batch tens of thousands of images without timeouts, switch models without changing code. Pay-as-you-go with no monthly fee — sign up here to get started.
	PackyCode is a stable and professional API relay for Claude Code, Codex, Gemini, and leading Chinese models. With fast unified access, full-stack observability, risk controls, elastic scaling, and cost optimization, it delivers a smooth developer experience. Sign up here to bring production-ready AI into your workflows.
	DEEIX-Chat is an open-source, self-hostable AI Chat platform for individuals, teams, and enterprises that need stable, long-term, unified access to multiple models. It brings models, conversations, files, tool calling, and administration together in one deployable and extensible system. Click here to start deploying.
	Right Code is an enterprise-grade AI Agent distribution platform that primarily provides stable access services for Claude Code, Codex, Gemini, and other models. It supports invoicing and dedicated one-to-one assistance for enterprises and teams. Thanks to Right Code for providing token support. Click here to register and get started.
	Swiftproxy provides 90M+ clean residential IPs across 220+ locations, supporting HTTP(S)/SOCKS5, IP rotation, Sticky Sessions, and precise location targeting. It helps API services and automation workflows access online platforms reliably from different locations, making it suitable for API requests, automation, data collection, and location-based access. Residential proxies start at $0.7/GB. Free testing is available, and code PROXY90 gives 10% off. Try Swiftproxy now.

Grok2API is a Go gateway with a built-in React admin console. It manages independent Grok Build, Grok Web, and Grok Console account pools and exposes unified OpenAI- and Anthropic-compatible APIs.

flowchart LR
    %% Color definitions
    classDef access fill:#e1f5fe,stroke:#01579b
    classDef core fill:#fff3e0,stroke:#e65100
    classDef providers fill:#f3e5f5,stroke:#4a148c
    classDef infra fill:#e8f5e9,stroke:#1b5e20
    classDef upstream fill:#fce4ec,stroke:#880e4f

    subgraph Access["Access Domain"]
        direction LR
        Clients["API Clients"]
        Admin["React Admin"]
    end

    subgraph Core["Gateway Core Domain"]
        direction LR
        Management["Management Services<br/>Accounts · Models · Keys · Settings"]
        Sync["Account Sync<br/>Credentials · Quota · Models"]
        Gateway["Gateway Service<br/>Protocols · Routing · Selection · Retry"]
        Audit["Audit Service<br/>Usage · Client Billing"]
        Management --> Sync
        Gateway -.-> Audit
    end

    subgraph Providers["Provider Channel Domain"]
        direction LR
        Registry["Provider Registry"]
        Build["Grok Build<br/>OAuth · Dynamic Models · Billing"]
        Web["Grok Web<br/>SSO · Remote Quota · Media"]
        Console["Grok Console<br/>SSO · Local Window · Stateless"]
        Registry --> Build
        Registry --> Web
        Registry --> Console
    end

    subgraph Infra["Shared Infrastructure Domain"]
        direction LR
        Egress["Egress Manager<br/>Scopes · Proxy Pool · Fallback · Clearance"]
        Database[("SQLite / PostgreSQL")]
        Runtime[("Memory / Redis")]
    end

    Upstream["🌐 Grok Upstream"]

    %% Cross-domain calls
    Clients --> Gateway
    Admin --> Management
    Gateway --> Registry
    Sync --> Registry
    Build -->|grok_build| Egress
    Web -->|grok_web / asset| Egress
    Console -->|grok_console| Egress
    Egress --> Upstream
    Management --> Database
    Audit --> Database
    Gateway <--> Runtime

    %% Application styles
    class Clients,Admin access
    class Management,Sync,Gateway,Audit core
    class Registry,Build,Web,Console providers
    class Egress,Database,Runtime infra
    class Upstream upstream

The Gateway routes requests through the Provider Registry. Account Sync refreshes credentials, quota, and models. Each Provider keeps independent account state and uses an isolated egress scope; usage, audits, and client billing are finalized after the request.

Each Provider keeps its own credentials, quota, health, cooldown, concurrency, and model capabilities. Account retries stay within one route; when one public model ID intentionally aggregates multiple routes, the gateway may select another schedulable route without mixing Provider state.

Official images support linux/amd64 and linux/arm64.

git clone https://github.com/chenyme/grok2api.git
cd grok2api
cp config.example.yaml config.yaml

Generate secrets and place them in config.yaml:

openssl rand -hex 32
openssl rand -base64 32

secrets:
  jwtSecret: "replace-with-the-generated-hex-value"
  credentialEncryptionKey: "replace-with-the-generated-base64-key"

bootstrapAdmin:
  username: "admin"
  password: "replace-with-a-strong-password"

Start the service:

docker compose pull
docker compose up -d
docker compose logs -f grok2api

Open http://127.0.0.1:8000. The image already includes the frontend; SQLite data and local media are stored in the Compose volume.

cp config.example.yaml config.yaml
make run

For frontend development:

cd frontend
pnpm install
pnpm dev

1. Sign in with the bootstrap administrator.
2. Connect a Build, Web, or Console account.
3. Wait for its quota and model capabilities to sync.
4. Review the public routes under Model Routes.
5. Create a client key under Client Keys.
6. Call a /v1/* endpoint with that key.

After first sign-in, change the administrator password and remove bootstrapAdmin from the configuration. Never rotate credentialEncryptionKey after credentials have been stored.

Imports accept UTF-8 BOM. Bulk quota sync, Build credential renewal, Web→Build/Console conversion, account tools, and cleanup report live progress.

Build refresh tokens may rotate when renewed. Do not actively share one Build credential between grok2api, the official CLI, another gateway, or another independent client: one client can consume a token that another client still holds. Authorize each active client separately, or transfer the credential only after the previous client has stopped using it.

Web account tools can accept the terms, set a random birthday corresponding to an age of 20–40, and enable NSFW. Completed steps are recorded and skipped on later runs.

Automatic deletion of old reauthRequired accounts is available but disabled by default. Active inference leases and video jobs are protected.

Build models are discovered from each account's actual capabilities. Web and Console use built-in catalogs. The Model Routes page shows Provider-qualified routes, endpoint capabilities, and supporting-account counts; clients should treat the currently serviceable results from GET /v1/models as authoritative.

Build does not use one global static model list. Account synchronization reads the upstream /models endpoint, and different accounts, subscription tiers, or staged rollouts may expose different models. Routing retains these per-account capabilities instead of replacing the global catalog with one account's response.

Conversation requests are translated to the Build Responses protocol while preserving the tool, reasoning, multi-turn, and prompt-cache compatibility required by Codex and Claude Code. Build currently exposes no image generation or image editing routes.

Web uses a built-in catalog filtered by account tier; higher tiers inherit lower-tier models.

Web Imagine generation maps aspect_ratio and n to the browser protocol. size remains an OpenAI-compatible aspect-ratio alias, while generation-only resolution and quality are ignored on Web routes because the upstream product is selected by the model name rather than by those Console-oriented controls.

Console uses the catalog built into the current release. Conversation forwarding is stateless, while image, video, and voice use the standard xAI resource APIs.

Generation and editing capabilities for the same Console image model are grouped into one logical model row; no separate -edit model copy is required.

Public names normally omit the Provider. Internally, routes use Build/, Web/, or Console/; qualified names can pin a request to one source.

Web can be weakly linked one-to-one with matching Build and Console accounts. Links share only an anonymous egress identity and provenance display. They never merge credentials, quota, health, cooldown, concurrency, capabilities, or billing.

Responses and Messages support streaming, tools, reasoning, multi-turn sessions, and compaction. Stable client session signals are preserved for Grok Build prompt-cache affinity. Cache hits still require a compatible upstream account and an unchanged prompt prefix. A still-decryptable g2a_compact_v1 summary from this gateway instance is expanded even if the session or PromptCacheKey remaps; an invalid prefixed blob is rejected with 400. Other compaction blobs keep their original encrypted_content when forwarded as upstream state, and any Build rejection is returned to the client.

Responses and Chat Completions report OpenAI-style total input. Messages reports Anthropic-style uncached input and cache reads separately. Audits retain total and cached input for billing reconciliation.

Inference endpoints use a client key:

Authorization: Bearer g2a_xxx_xxx

Stored responses and compact depend on the selected Provider. The signed-in admin console provides live examples at /docs; Swagger is available only when server.swaggerEnabled: true.

/v1/audio/transcriptions supports json (default), verbose_json, and text. Video edit/extension routes must resolve to Console grok-imagine-video; custom public model names remain supported. Monetary billing is applied only when the gateway can reliably measure the official pricing unit: TTS is reserved and settled from its input character count, while REST and streaming STT are settled from the actual audio duration returned by a successful response. Because STT duration is known only after completion, concurrent requests may briefly take a billing-limited key beyond its spend limit. Realtime, video edits/extensions, and custom routes without a recognized official price are currently audited as unpriced; they remain callable and do not consume the spend limit.

Client keys support model allowlists and optional RPM, concurrency, spend, and expiry limits.

curl http://127.0.0.1:8000/v1/responses \
  -H "Authorization: Bearer g2a_xxx_xxx" \
  -H "Content-Type: application/json" \
  -d '{
    "model": "your-model",
    "input": "Explain quantum tunneling in three sentences.",
    "stream": true
  }'

Egress nodes are scoped to Build, Web, Console, or Web assets. The admin console supports:

• HTTP, HTTPS, SOCKS4/4A, SOCKS5/5H, Resin, Trojan, VLESS, Shadowsocks, and VMess
• TCP, WebSocket, and TLS tunnel transports; unsupported variants are rejected during import
• Subscription and text/Base64 import
• Batch probes, filtering, deletion, assignment, and balancing
• Fallback per scope: none, direct, or a fixed node
• Proxy-pool mode without global cooldown after one connection failure
• Immediate recovery probes after fixed-proxy transport failures, with per-node coalescing and bounded waiting for fast retry
• Optional Egress Quality Guard for active per-node model probes, guarded quarantine, and recovery; enable it with the built-in quality-guard Compose profile
• Nodes whose proxy username contains {account} are treated as lease-scoped: a passive anomaly temporarily removes only the audited account lease, then recovery pins the probe to that same account and node. An unhealthy probe renews the hold; an expired hold no longer blocks routing if the sidecar is unavailable, so stale guard state cannot strand an account indefinitely. The shared node is never disabled and the rendered proxy identity is never exposed. Ordinary fixed sticky sessions can still be managed as separate nodes

Hysteria and TUIC are not supported yet. FlareSolverr accepts only HTTP/SOCKS proxy URLs, so automatic clearance refresh cannot use a tunnel share URL directly.

To enable the guard, add a qualityGuard section to config.yaml, then start the profile. The main service creates and reuses a non-exportable system probe identity automatically:

qualityGuard:
  enabled: true
  model: "grok-4.6"
  # Withhold thinking-model streams that have no streamed reasoning.
  # Observe for up to 30s. A stub plus enough visible output at the deadline
  # is withheld; empty stub-only streams keep waiting. Floor-met dumps that
  # flush a short greeting in under 1s are also withheld.
  requestRetry:
    enabled: true
    maxAttempts: 6
    holdTimeout: 30s
    minOutputTokens: 8
    onExhausted: fail_closed # fail_open | fail_closed
    accountCooldown: 12h
    idleAccountCooldown: 15m

requestRetry runs on the gateway request path and is independent of the sidecar. config.example.yaml keeps enabled: false; set it true to intercept. When enabled, a thinking-model stream with enough visible output and no streamed reasoning is not delivered; replay-safe stateless requests may try another account. TUI follow-ups (previous_response_id) and hosted-tool turns are still held for classification, but a quality withhold never replays account-bound state or side-effecting tools across accounts; onExhausted returns 503 quality_degraded or releases that held body. Context compaction, image, video, and ForcedEgress probe requests are unchanged.

docker compose --profile quality-guard up -d --build

Existing preview deployments that still contain clientKeyID can upgrade directly. The field is accepted for compatibility but ignored and can be removed; any manually created probe key is intentionally left untouched.

After changing this configuration, run docker compose --profile quality-guard restart grok2api egress-quality-guard to reload the base settings; policy edits made in the admin page still hot-reload.

The normal docker compose up -d command does not start the guard or generate probe traffic. The sidecar receives a narrowly scoped internal credential from the main service and never stores or uses the administrator password. See the linked guide before enabling automatic quarantine.

Resin usernames can contain {account}:

socks5h://Default.{account}:RESIN_PROXY_TOKEN@resin:2260

The placeholder becomes a stable anonymous identity. Linked Web, Build, and Console accounts can share it; raw tokens and email addresses are not used.

For managed Web/Console Cloudflare Clearance:

docker compose --profile flaresolverr up -d

Then use http://flaresolverr:8191 under Runtime Settings → Media & Network → Clearance and select one of the managed modes:

• FlareSolverr proactively refreshes stale fixed-egress Clearance on the configured schedule.
• On demand keeps the last successful Clearance regardless of age and solves again only after an upstream rejection explicitly invalidates it. Scheduled refresh does not launch a browser in this mode.

Manual never invokes FlareSolverr. The on-demand mode can make the first request without a managed Clearance; if Cloudflare rejects it, the next lease performs one deduplicated solve.

The egress layer retries only connection failures known to occur before request submission. It does not replay submitted generation requests, authentication failures, exhausted quotas, or upstream rate limits.

When a fixed proxy enters cooldown after a transport failure, grok2api starts an independent connectivity probe immediately. Concurrent failures share one probe. A later request bound to that node waits for at most five seconds, reloads persisted node state after a healthy probe, and continues without waiting for the full cooldown. An unhealthy probe preserves the cooldown. Proxy-pool leases use fresh tunnels, so one rotating exit failure never cools the whole pool. See Immediate egress failure probe and bounded retry for the design and safety invariants.

config.yaml contains startup settings; Provider and operational settings are managed in the admin console and hot-reload unless marked otherwise.

Multi-instance deployments require a unique deployment.instanceID per replica, one shared clusterID, and sharedMedia: true only after the media directory is shared correctly.

PostgreSQL credentials can be injected without storing them in config.yaml:

GROK2API_DATABASE_URL='postgresql://user:password@host:5432/grok2api?sslmode=require' docker compose up -d

A non-empty GROK2API_DATABASE_URL overrides database.postgres.dsn and automatically selects the postgres driver. An empty value is ignored. Supported URL schemes are postgres:// and postgresql://; SQLAlchemy's postgresql+asyncpg:// form is rejected with a migration hint. The application does not implicitly read the generic DATABASE_URL; platforms that provide it can map it explicitly with GROK2API_DATABASE_URL: "${DATABASE_URL}". Database configuration precedence is built-in defaults, config.yaml, then GROK2API_DATABASE_URL. The current CLI has no database override.

Request audits record the normalized client IPv4 or IPv6 address. Direct deployments need no extra configuration. Behind Nginx or another reverse proxy, configure both sides:

1. Forward the standard client IP headers from the proxy:

location / {
    proxy_pass http://127.0.0.1:8000;

    proxy_set_header Host $host;
    proxy_set_header X-Real-IP $remote_addr;
    proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
    proxy_set_header X-Forwarded-Proto $scheme;
}

1. Trust only the proxy address or its isolated network in config.yaml:

server:
  trustedProxies:
    - "127.0.0.1"

With Docker, the peer seen by grok2api may be the bridge gateway or another container rather than 127.0.0.1. Inspect the Compose network before configuring it:

docker network inspect grok2api_default \
  --format '{{(index .IPAM.Config 0).Subnet}}'

For example, an isolated network reported as 172.20.0.0/16 can be configured as a trusted proxy CIDR. Never use 0.0.0.0/0 or ::/0; grok2api rejects unrestricted trusted-proxy ranges. Without trustedProxies, forwarded headers are ignored and audits contain the direct TCP peer address, preventing clients from spoofing X-Forwarded-For.

If Cloudflare is in front of Nginx, configure Nginx's real-IP module with CF-Connecting-IP and Cloudflare's official proxy ranges first. Do not trust CF-Connecting-IP from arbitrary peers. Restart grok2api after changing server.trustedProxies; reload Nginx after changing its configuration.

Important optional settings:

• audit.ledgerMode: observe reports ledger faults; enforce can pause new inference to protect billing integrity.
• routing.accountIsolatedConnections: partitions outbound TCP/HTTP pools by account for external L4 or connection-hash load balancers. It is off by default because it increases connections, TLS handshakes, memory, and file-descriptor usage.
• routing.segmentedSelectorEnabled: enabled by default for pools with at least 3,000 eligible accounts; bounds dynamic concurrency reads while retaining quota/tier priorities, sticky sessions, full-planner fallback, and atomic guards.
• routing.autoAssignMaxNodeShare / routing.autoAssignMaxMigrationShare: optional large-pool guards. 0 (default) keeps the historical unbounded first-pass evacuation and the existing 200-move ceiling for capacity/rebalance repair. Set 0.05–1 only when a quarantined node would otherwise dump thousands of auto accounts onto the last healthy exits. GROK2API_AUTO_ASSIGN_MAX_NODE_SHARE and GROK2API_AUTO_ASSIGN_MAX_MIGRATION_SHARE override the YAML when set.
• Build response-header timeout and exact-match 403 invalidation rules are hot-reloadable.
• Sync latest version applies the validated Grok Build client version and User-Agent.

• Use HTTPS and enable auth.secureCookies.
• Keep Swagger disabled on public deployments.
• Use strong, backed-up secrets; never commit credentials, cookies, exports, or databases.
• Back up config.yaml, the database, and media storage.
• Use PostgreSQL, Redis, and shared media for multiple instances.
• Put a reverse proxy and access controls in front of public deployments.

cd backend
go test ./...
go test -race ./...
go vet ./...
go build ./cmd/grok2api

cd frontend
pnpm install --frozen-lockfile
pnpm lint
pnpm build

Regenerate Swagger after changing public API annotations:

make swagger
